The NT6 from Rode is a professional general-purpose condenser microphone that exhibits the convenience of flexible placement, making it a strong candidate for instrument capturing in recording and sound-reinforcement applications. Capitalizing on the success of the renowned NT5, the engineers at Rode integrated its cardioid capsule into the miniature design of the NT6.
The NT6 features a detached microphone head (capsule) and body (output stage). A 10' Kevlar-reinforced cable attaches these two components and enables flexible microphone mounting and placement. The NT6 features a cardioid polar pattern which effectively minimizes noise due to off-axis ambient audio and feedback. A -10 dB Pad switch provides added headroom, allowing excessively loud signals, such as brass and percussion, to be captured without noise or distortion. A low-frequency roll-off switch eliminates low-frequency noise and rumble below 80 Hz.
Miniature Detached Capsule and Body
A 10' Kevlar-reinforced microphone cable joins the miniature capsule and output stage. This design provides endless mounting possibilities on instruments, the ability to capture room ambiance, and more.
Swivel Mount
The 2-position swivel mount allows both horizontal and vertical pivoting of the capsule for accurate positioning. Also included are 2 thread adapters (1/4" to 5/8" and 1/4" to 3/8") which enable attachment to virtually any microphone stand.
Cardioid Polar Pattern
The cardioid polar pattern effectively suppresses off-axis audio, reducing residual noise caused by ambiance and feedback.
Low-Frequency Roll-Off
A low-frequency roll-off switch eliminates noise and rumble below 80 Hz.
-10 dB Pad Switch
A -10 dB pad switch provides added headroom for capturing signals that exhibit excessive level and transients. The pad allows these signals to be captured without noise caused by distortion and overload.
| Operating Principle | Pressure Gradient |
| Transducer | Condenser |
| Diaphragm | 0.5" / 12.70 mm |
| Polar Pattern | Cardioid |
| Frequency Range | 40 Hz to 20 kHz |
| Signal to Noise Ratio | 75 dB |
| Equivalent Noise Level | 19 dB A-Weighted |
| Maximum SPL | 135 dB SPL 1% |
| Pad | 0 dB 10 dB |
| Impedance | 200 ohms |
| Sensitivity | -37 dB, re: 1 V/Pa |
| Dynamic Range | 119 dB |
| Output Connectors | 3-Pin XLR |
| Power Requirements | 24 V, 48 V |
| Length | 7.44" / 189 mm |
| Diameter | 2.52" / 64 mm |
| Weight | 0.85 lb / 386 g |
